C12100 Copper Pipe Description
C12100 copper pipe is widely recognized for its excellent conductivity and resistance to corrosion, making it ideal for various industrial, plumbing, and HVAC applications. This high-quality copper pipe ensures long-lasting durability, efficient heat transfer, and reliable performance in demanding environments. With its smooth inner surface, C12100 copper pipe reduces friction and supports optimal fluid flow. The versatility of this pipe makes it suitable for both residential and commercial installations. Known for its superior material properties, C12100 copper pipe remains a trusted choice for professionals seeking dependable, cost-effective piping solutions.
Product Parameters
|
Outer Diameter |
2mm-300mm, or customized |
Wall Thickness |
0.2mm-50mm, or customized |
|
Length |
Customized |
Standard |
ASTM, AISI, JIS, GB, DIN, EN |
|
Brand |
C10100, C10200, C10300, C10400, C10500, C10700, C10800, C10910, C10920, C10930， C11000, C11300, C11400, C11500, C11600, C12000, C12200, C12300, C12500, C14200, C14420, C14500, C14510, C14520, C14530, C17200, C19200, C21000, C23000, C26000, C27000, C27400, C28000, C33000, C33200, C37000, C44300, C44400, C44500, C60800, C63020, C65500, C68700, C70400, C70620, C71000, C71500, C71520, C71640, C72200， T1, T2, T3, TU1, TU0, TU2, TP1, TP2, TAg0.1, ect. |
||
|
Surface Finish |
Grinding, Polishing, Brightening, Oiling, Hair Thread, Brush, Mirror, Sandblasting or Processing As Required |
||
|
Certification |
ISO, SGS, BV |
Payment Method |
FOB, CRF, CIF, EXW Acceptable |
|
Port of Loading |
Any port in China |
Delivery Time |
Received 30% after deposit 7-15 working days |
Chemical Composition
|
Copper+Silver With Ag: |
Tin Sn: |
Zinc Zn: |
Lead Pb: |
Nickel It is: |
Iron Fe: |
|
≥ 99.90 |
≤ 0.002 |
≤ 0.005 |
≤ 0.005 |
≤ 0.005 |
≤ 0.01 |
|
Antimony Sb: |
Sulphur S: |
Arsenic As: |
Bismuth Bi: |
Oxygen O: |
Phosphorus P: |
|
≤ 0.002 |
≤ 0.005 |
≤ 0.002 |
≤ 0.002 |
≤ 0.01 |
0.005～0.012 |
Mechanical Properties
|
Tensile Strength Kb (MPa): |
Elongation D10 (%): |
Hardness: |
|
245～345 |
≥ 8 |
75～120HV |
Scope of Application
| Uses and Applications of Copper | |
| Power Industry | Power transmission such as line cables, transformers, switches, plug components and connectors, etc.; motor manufacturing such as stator, rotor, shaft head and hollow wire, etc.; communication cables and residential electrical lines also need to use a large number of copper wires. |
| Electronic Industry | Electric vacuum devices such as high-frequency and ultra-high-frequency emission tubes, catheters, magnetrons, etc., they need high-purity oxygen-free copper and dispersion-strengthened oxygen-free copper. Copper printed circuits require a large amount of copper foil and copper-based brazing material. Integrationin the circuit
Copper replaces aluminum in silicon chips for interconnect lines and lead frames. |
| Energy and Petrochemical Industry | The main condenser tube plate and condenser tube of the energy industry thermal power plant are made of brass, bronze or cupronickel. Solar heaters are also often manufactured using copper tubing. Petrochemical industry copper and many copper alloys, used in large quantities to manufacture contact corrosion
Various media containers, piping systems, filters, pumps and valves, various evaporators, heat exchangers and condensers, etc. |
| Transportation Industry | In the shipbuilding industry, copper alloys include aluminum bronze, manganese bronze, aluminum brass, gunmetal (tin zinc bronze), white copper and nickel copper alloy (Monel alloy), etc. are all standard materials for shipbuilding. In warships and merchant ships, copper and copper alloys are generally used as aluminum bronze propeller,
Bolts, condenser tubes, rivets, copper coated paint, etc. In the automotive industry, copper and copper alloys are mainly used in radiators, brake system pipelines, hydraulic devices, gears, bearings, power distribution and power systems, brake friction plates, washers and various joints, Accessories and trims, etc. The motors, rectifiers and control, braking, electrical and signal systems on railway trains also rely on copper and copper alloys to work. In addition, the electrification of railways requires a large amount of copper and copper alloys.in the aircraft Copper for wiring, hydraulic, cooling and pneumatic systems, aluminum bronze tubing for bearing retainers and landing gear bearings, and diamagnetic copper alloy for navigation instruments. |
| Mechanical and Metallurgical Industries | In addition to a large number of copper used in motors, circuits, hydraulic systems, pneumatic systems and control systems in mechanical engineering, various transmission parts and fixing parts, such as cylinder liners, connectors, fasteners, gears, twisting parts, etc., all Need to reduce wear and lubrication with copper or copper alloy.
The key component in continuous casting technology of metallurgical equipment-crystallizer, mostly made of high strength and high thermal conductivity copper alloy such as chromium copper, silver copper, etc., and the vacuum arc furnace and electroslag furnace water-cooled crucible in electrometallurgy are made of copper pipe, and various induction heating The induction coils are all made of copper tubes or special-shaped copper tubes, which are cooled by water. |
| Light Industry | Copper and copper alloy can be used in the manufacture of air conditioner heat exchanger, watch movement, paper machine mesh, roller, printing copper plate, fermentation tank lining, distillation pot, building decoration components, etc. |
| Emerging Industries and High-tech Fields | Copper is also used in emerging industries and high-tech fields, such as superconducting alloy jackets, ultra-low temperature medium containers and pipelines, rocket engine cooling village, high-energy accelerator magnet windings. |
